| ISE1L | For low pressure | 0 to 100 kPa | ?10 to 0 kPa | 500 kPa | Air/Non-corrosive, non-flammable gas | 12 to 24 VDC ?10%, Ripple (P-P)10% or less (With power supply polarity protection) | 1 output: 17 mA or less at 24 VDC, 2 output: 25 mA or less at 24 VDC | 5 ms or less | ?1% F.S. or less | IP40 | Operating: 0 to 60C, Stored: ?10 to 60C (With no condensation and no freezing) | Operating/Stored: 35 to 85%RH (With no condensation) | 10 to 500 Hz at whichever is smaller of 1.5 mm amplitude or 98 m/s2 acceleration, in X, Y, Z directions for 2 hrs. each (De-energized) | 980 m/s2 in X, Y, Z directions, 3 times each (De-energized) | ?3% F.S. or less | 1000 VAC for 1 min. (between live parts and case) | 50 M or more (at 500 VDC by megameter) between live parts and case | 01: R 8, M5 x 0.8 T1: NPTF 1/8, M5 x 0.8 00: ZM ejector mount type | 40 g (Including 0.6 m-Long lead wire) | Oil-resistant vinyl cabtire code 3 cores, ?3.4, Cross section: 0.2 mm2, Insulator O.D.: 1.1 mm | Heat-resistant vinyl electric wire, 4-wire, Cross section: 0.3 mm2, Insulator O.D.: 1.55 mm | Compliant with CE marking |
