O-012-062 - .012" Precision Polycarbonate Orifice Restrictor with 1/16" Barbs (Green)

Part Number: O-012-062

Series image - for reference only
Please pull down this page to review full catalog specifications PDF

Your Price: $1.40

Availability:

Available to Ship Today*: 801 qty

The item you are trying to purchase is currently out of stock.
Please enter your name, email, and phone number below.
We will contact you as soon as this product is available.

Name: *

Email: *

Phone: *

Verification: *

Type the word above...

Quantity

Description

OCP EDI: O012062

Precision molded orifices feature accuracy comparable to jewel orifices at a fraction of the cost. Color coded for easy identification. Barbed connections allow higher working pressures.

Specifications

Accuracy: Orifice Size ±.003”
Material: FDA Approved Polycarbonate
Max Operating Pressure: 100 PSI
Connection: Straight Connection for 1/16" I.D. Tubing
Repeatability: ±.0002" or ±3% Flow whichever is greater

Size	Color	Part Number
		With 1/16" Barbs	With 1/8" Barbs
.003	Gold	O-003-062	O-003-125
.004	Purple	O-004-062	O-004-125
.005	White	O-005-062	O-005-125
.007	Yellow	O-007-062	O-007-125
.008	Lt. Green	O-008-062	O-008-125
.009	Lavender	O-009-062	O-009-125
.010	Lt. Blue	O-010-062	O-010-125
.012	Green	O-012-062	O-012-125
.014	Orange	O-014-062	O-014-125
.016	Grey	O-016-062	O-016-125
.017	Brown	O-017-062	O-017-125
.019	Red	O-019-062	O-019-125
.020	Dk. Blue	O-020-062	O-020-125
.025	Black	O-025-062	O-025-125
.030	Beige	O-030-062	O-030-125
.035	Dk. Grey	O-035-062	O-035-125
.040	Teal	O-040-062	O-040-125
