RMW-920-90-W/K - No Bleed Precision Pressure Regulator - 10-32 Ports - 90 PSI with Adjusting Knob

Part Number: RMW-920-90-W/K

Series image - for reference only
Please pull down this page to review full catalog specifications PDF

Your Price: $38.85

Availability:

Available to Ship Today*: 25 qty

The item you are trying to purchase is currently out of stock.
Please enter your name, email, and phone number below.
We will contact you as soon as this product is available.

Name: *

Email: *

Phone: *

Verification: *

Type the word above...

Quantity

Description

The RMW-900 Series regulators are designed for applications requiring miniature size, light weight, and precision. 10-32 ports accommodate a wide range of miniature fittings.

Features

Twenty turn, hysteresis free adjustment allows pressure settings to 1” WC resolution.
Four adjusting styles allow maximum design flexibility. The non-rising stem is available with an attractive knob, or plain, allowing installation of OEM knobs. Also available is a flush adjusting shaft, for applications where the setting is changed less frequently. Factory pre-set “tamperproof” models are also available.
Three mounting options include panel mount, through a 9/16” hole (nut included), and base mount, through 4 ø .125 holes, and manifold mount (See drawings).
Plastic construction - Corrosion resistant wetted materials.
High accuracy - Low effect of supply variation on output.
Low cost - Perfect for OEM applications.
Applications:
- Medical Equipment (Oxygen Concentrators, Ventilator / Respirators, Nebulizers)
- Air Bearings
- HVAC Systems
- Custom Machinery
- Robotics
Options:
- Oxygen Clean
- Factory Preset
- Factory Installed Fittings

Specifications

Regulator Type: Non-Bleed, Relieving
Wetted Materials: Polysulfone, Buna-N, EPDM, Acetal, Polyurethane, Stainless Steel
Supply Consumption: < .3 SCIM (5 cc/min.) Note: RMW-920 series regulators have “near zero” bleed to atmosphere under normal operating conditions. Should any overshoot, or downstream pressure increases occur, the unit will relieve only what is necessary to stabilize the pressure setting. Important: Proper filtration is a must to maintain correct operation of the RMW-920 Series. Medical White cannot guarantee perfect “non-bleed” operation under any circumstances. Consult with a Medical White Application Engineer for more information.
Max Supply: 150 PSI (1.03 MPa)
Temperature Range: 40° - 150° F (4° - 66° C)
Effect of Supply Variation: < .1 PSI (.69 kPa) per 5 PSI (34.5 kPa) supply change
Repeatability: < ±.25 PSI (1.72 kPa) when supply is removed and re-applied
Sensitivity: 2" H₂O (.5 kPa)
Maximum Flow: 2.3 cu. ft/min. (65 LPM)
Relief Capacity: .5 cu. ft/min. (14 LPM) with outlet 5 PSI (34.5 kPa) above set-point
Recommended Filtration: 5 micron

Available Pressure Ranges (PSI): 0.5 - 3.5, 0.5 - 10, 0.5 - 30, 0.5 - 60, 0.5 - 90

Stocked Configurations Below Can Ship Same Day

Part Number	Description
RMW-920-3.5-W/K	3.5 PSI with Adjusting Knob
RMW-920-10-W/K	10 PSI with Adjusting Knob
RMW-920-30-W/K	30 PSI with Adjusting Knob
RMW-920-60-W/K	60 PSI with Adjusting Knob
RMW-920-90-W/K	90 PSI with Adjusting Knob
